When police forces, law enforcement, and rescue organizations are on mission, real-time target information behind walls and obstacles is critical to strategic planning and mission success.
The invention of ultra-wideband (UWB) radar makes it possible to obtain accurate target position and motion information and target number behind common walls such as concrete, soil, rock, mixed bricks, etc. in real time. UWB radar works at low frequencies, uses a very wide bandwidth, and can achieve strong penetration and high resolution.
Using advanced through-the-wall imaging technology, NovoQuad The team developed 2D & 3D Perspective Wall Radar System With high penetration, high resolution and long detection range, it is suitable for anti-terrorism operations, natural disaster rescue missions and avalanche recovery searches. The radar main unit can be mounted on the wall or placed away from the wall. The terminal PAD can be connected as a unit to the radar mainframe, or it can be operated remotely by a field engineer at a secondary location. The 3D positioning display can provide the height and attitude information of the target.
2D Perspective Wall Radar System
ND-SV003 Perspective Wall Radar System It is a 2D version of the see-through wall radar system, which can detect multiple moving and static targets at the same time, and perform 2D positioning and display.
The main features of ND-SV003 are as follows.
- Strong penetrating ability
Able to penetrate thicker ordinary walls such as concrete, soil, rock, mixed brick.
- high resolution
Ability to detect objects with high resolution in distance and orientation.
- Detect multiple targets in real time
Capable of detecting and displaying multiple moving and static targets in real time.
- Play back the entire inspection process
The entire detection process and target trajectory can be reported for further analysis.
- Strong adaptability to the environment
Capable of operating in all weather conditions, unaffected by rain, fog, snow, dust, smoke or darkness.
3D Perspective Wall Radar System
ND-SV009 Portable 3D Perspective Wall Radar System, is a 3D portable version of the see-through wall radar system, which has obvious advantages in 3D positioning and portable structure. Due to its reliable detection performance, small size and light weight, the ND-SV009 can quickly detect moving and static targets to assist in the entire search, rescue and protection mission.
In addition to the features of the 2D version, the ND-SV009 has the following features.
- 3D positioning display
Ability to detect and display multiple moving and static objects and movement trajectories in 3D localization.
- Get more target information
It can obtain the height and attitude information of the target.
- portable structure
Small size, light weight, easy to carry and quick to operate.
Concrete and brick walls may seem impenetrable, but advanced through-wall imaging technology allows us to see the exact scene behind the wall. Real-time information and imaging of living targets behind walls obtained by NovoQuad’s see-through wall radar systems will aid in search and rescue, counter-terrorism and protection missions, preventing terrorist activity and crime and saving lives.
To learn more about NovoQuad’s 2D and 3D see-through wall radar systems, please refer to the links below, or send your enquiry to info@nqdefense.com.
ND-SV003 Perspective Wall Radar System
ND-SV009 Portable Perspective Wall Radar System
